Juniper Juniper Certifications JN0-361 Questions & Answers

• Question 421:

  Which BGP state denotes a fully operational session?

  A. Established

  B. Active

  C. Operational

  D. Connect

  Correct Answer: A

• Question 422:

  Which two values displayed in the output from the show spanning-tree MSTP configuration command must match on all switches participating in the same MSTP region? (Choose two)

  A. root bridge identifier

  B. authentication checksum

  C. context identifier

  D. configuration digest

  Correct Answer: CD

• Question 423:

  Which role does the router ID (RID) have in the BGP route selection process?

  A. The router ID is evaluated immediately after MED to determine route preference

  B. The router ID is evaluated last in the route selection process

  C. The router ID is evaluated after the cluster length and a lower router ID is chosen

  D. The router ID is evaluated after analyzing the IGP metric cost

  Correct Answer: C

  Reference: http://www.juniper.net/techpubs/en_US/junos10.0/information-products/topic-collections/nog-baseline/bgproutes-and-selection-introduction.html

• Question 424:

  You are logged into a router and have navigated to the [edit routing-options] level of the hierarchy. You have been asked to create a static route that will use 43 18 7 1 as its primary next-hop and 76 1310 2 as its secondary next-hop.

  Which command correctly configures this setup?

  A. set static route 0/0 76.13.10.2 qualified-next-hop 43.18.7.1 pref 10

  B. set static route 0/0 next-hop 43.18.7.1 secondary-next-hop 76.13.10.2 preference 10

  C. set static route 0/0 next-hop [76.13.10.2 10.10.10.5] pref 10

  D. set static route 0/0 next-hop 43.18.7.1 qualified-next-hop 76.13.10.2 preference 10

  Correct Answer: D

• Question 425:

  You have configured an IP-IP tunnel between Router A and Router B

  Which Junos operational mode command is used to verify that the tunnel interface is up and operational?

  A. show chassis tunnel status

  B. show tunnel interface

  C. show interfaces terse

  D. show interfaces tunnel

  Correct Answer: C

• Question 426:

  Which IS-IS packet is used to determine the level of an IS-IS neighbor?

  A. IIH

  B. LSP

  C. PSNP

  D. CSNP

  Correct Answer: A

• Question 427:

  Router A is an OSPF router connected to both Area 0 and Area 1 Area 1 has been configured as a stub area Which two LSA types does Router A suppress from Area 1?

  A. Router LSA

  B. External LSA

  C. Summary LSA

  D. ASBR Summary LSA

  Correct Answer: BD

• Question 428:

  You are logged into a router and have navigated to the (edit routing-options] level of the hierarchy. You have been asked to create a static route that will use 10.10.10.1 as its primary next-hop and 10.10.10.5 as its secondary next-hop.

  Which command correctly configures this scenario?

  A. set static route 8/8 10.10.10.1 qualified-next-hop 10.10.10.5 pref 10

  B. set static route 8/8 next-hop 10.10.10.1 secondary-next-hop 10.10.10.5 preference 10

  C. set static route 8/8 next-hop 10.10.10.1 qualified-next-hop 10.10.10.5 preference 10

  D. set static route 8/8 next-hop [10.10.10.1 10.10.10.5] pref 10

  Correct Answer: C

• Question 429:

  Which Junos operational mode command is used to verify that load balancing is working as expected?

  A. show route all

  B. show route extensive

  C. show route balancing

  D. show route forwarding-table

  Correct Answer: D

• Question 430:

  Click the Exhibit button Based on the illustration of the VPLS topology shown in the exhibit, which statement is true?



  A. PE-C must have a spanning-tree protocol enabled

  B. CE-C must have BGP enabled

  C. Traffic forwarded from PE-C to PE-A is forwarded on to PE-B

  D. Traffic forwarded from PE-C to PE-A is not forwarded on to PE-B

  Correct Answer: D
