OMG OMG Certifications OMG-OCUP2-INT200 Questions & Answers

• Question 71:

  How many arrows can connect to a partition?

  A. any number

  B. none

  C. two

  D. one

  Correct Answer: B

• Question 72:

  In the exhibit, what applies if the interaction constraint is false when the loop is entered?



  A. All valid traces will include message r.

  B. Valid traces include both the case where the loop iterates once, and when it iterates zero times.

  C. The specification if illegal.

  D. The loop body is not included in a valid trace.

  Correct Answer: A

• Question 73:

  In the exhibit, what is true for Massert?



  A. A message q that occurs before a message p is invalid.

  B. Following a message p, a message m would be valid.

  C. Following a message p, a message m would be invalid.

  D. A message p may come anywhere in the assert combined fragment.

  Correct Answer: C

• Question 74:

  What does the history of a state represent?

  A. most recent transition that was taken out of the state

  B. most recent active configuration of its substates

  C. number of times that the state has been active before

  D. most recent transition that was taken into the state.

  Correct Answer: B

• Question 75:

  What best describes the semantics modeled by the exhibit?



  A. Order Entry and Invoicer are ports of Order Entry

  B. Order Entry delegates to both Order Entry and Invoicer.

  C. The order Entry component and the Invoicer component both require the services described by the Order interface and use an Order Entry component that provides those services.

  D. Signals travel from an Order Entry port and an Invoicer port, and join into a composite signal that flows to an Order Entry port. The signals flow along instances of the Order interface.

  Correct Answer: C

• Question 76:

  In the exhibit, what is true about the deployment location?



  A. is at the "instance" level

  B. is parameterized by four Deployment Specifications

  C. is over-crowded

  D. is at the "type" level

  Correct Answer: A

• Question 77:

  What types of features may a component possess?

  A. attributes, but not operations

  B. attributes and operations

  C. neither attributes nor operations

  D. operations, but not attributes

  Correct Answer: B

• Question 78:

  What is correct about a profile? (Choose two.)

  A. is applied to a package

  B. cannot be used without its reference model

  C. can dynamically change its reference metamodel

  D. is applied to a reference metamodel

  Correct Answer: AB

• Question 79:

  When either a message m or a message q is to be sent-but not both-what kind of operator for combined fragment would be used?

  A. var

  B. break

  C. opt

  D. par

  E. alt

  Correct Answer: E

• Question 80:

  What is a combined fragment?

  A. more than one interaction combined in an interaction overview diagram

  B. an interaction occurrence covering more than one lifeline

  C. the combination of decomposed lifelines

  D. a construct with interaction operands and in interaction operator.

  Correct Answer: D
