F5 F5 Certifications 101 Questions & Answers

• Question 351:

  A site needs a virtual server that will use an iRule to parse HTTPS traffic based on HTTP header values. Which two profile types must be associated with such a virtual server?

  (Choose two.)

  A. TCP

  B. HTTP

  C. HTTPS

  D. ServerSSL

  Correct Answer: AB

• Question 352:

  A, steaming profile will do which of the following?

  A. Search and replace all occurrences of a specified string only is responses processed by a virtual server.

  B. Search and replace all occurrences of a specified string only in request processed by a virtual server.

  C. Search and replace all occurrences of a specified string in requests and responses processed by a virtual server.

  D. Search and replace the first occurrence of a specified of a specified string in either a request or response processed by a virtual server.

  Correct Answer: C

• Question 353:

  Which event is always triggered when the client sends data to a virtual server using TCP?

  A. HTTP_DATA

  B. CLIENT_DATA

  C. HTTP_REQUEST

  D. VS_CONNECTED

  Correct Answer: B

• Question 354:

  Administrators can configure which three of the following load balancing options in GTM? (Choose three.)

  A. Alternate

  B. Fallback

  C. Required

  D. Preferred

  E. Backup

  F. Optional

  Correct Answer: ABD

• Question 355:

  An F5 customer must install WebAccelerator on top of LTM:

  A. True

  B. False

  Correct Answer: B

• Question 356:

  Which of the following statements best describes the ARX architecture?

  A. The ARX's split path architecture has a data path that handles the most common operations, and a control path that handles other operations requiring deeper inspection and updating of the index.

  B. The ARX's architecture has redundancy built in, allowing a single ARX to be deployed in most use cases which provides a huge cost savings to customers.

  C. All of the above.

  D. It is a software agent that installs on the storage device.

  Correct Answer: A

• Question 357:

  If a client's browser does not accept cookies, what occurs when the client connects to a virtual server using cookie persistence?

  A. The connection request is not processed.

  B. The connection request is sent to a pology.server. The connection request is sent to a pology.server.

  C. The connection request is load balanced to an available pool member.

  D. The connection request is refused and the client is sent a "server not available" message.

  Correct Answer: C

• Question 358:

  Adding more RAM to a GTM device drastically improves query performance.

  A. True

  B. False

  Correct Answer: B

• Question 359:

  Tightening is a feature of which type of entity?

  A. Explicit URLs

  B. Attack signatures

  C. Flow login URLs

  D. Wildcard parameters

  Correct Answer: D

• Question 360:

  Which three of the following must be done in order for GTM to properly communicate LTM? (Choose three.)

  A. Connect the GTM and LTM with a network crossover cable.

  B. Synchronize the big3d versions between GTM and LTM.

  C. Add the LTM object to the GTM configuration.

  D. Configure the GTM and LTM to we MAC masquerading.

  E. Ensure that GTM and LTM use the same floating IP address.

  F. Exchange SSL certificates between the two devices.

  Correct Answer: BCF

  Integrating LTM systems with GTM systems on a network Running the bigip_add utility

  Determine the self IP addresses of the BIG-IP LTM systems that you want to communicate with BIG-IP GTM.

  Run the bigip_add utility on BIG-IP GTM. This utility exchanges SSL certificates so that each system isauthorized to communicate with the other. When the LTM and GTM systems use the same version of the big3d agent, you run the

  bigip_add utility toauthorize communications between the systems. http://support.f5.com/kb/en-us/products/big-ip_gtm/manuals/product/gtm- implementations11-3-0/7.html

  Note:

  The BIG-IP GTM and BIG-IP LTM systems must have TCP port 4353 open through the firewall between the systems. The BIG-IP systems connect and communicate through this port.
