Cisco CCNP Data Center 350-601 Questions & Answers

• Question 311:

  Refer to the exhibit.



  Server1 is connected to a Cisco Nexus 9000 Series Switch via a 1-Gb port channel. The storm control is applied to the Eth0 device with a zero percent value. What does the switch do to traffic that traverses the switch interfaces during the streaming window that exceeds the bandwidth of the interfaces?

  A. forwards all traffic

  B. forwards half of the traffic

  C. suppresses all traffic

  D. drops all of the excess traffic

  Correct Answer: C

• Question 312:

  An engineer configures port security on a Cisco MDS 9000 Series Switch. The MDS switch configuration must meet these requirements

  1.

  The switch must inmate the VSAN 4 port security database despite any conflicts.

  2.

  New devices must be statically added to the switch.

  3.

  Configuration changes for VSAN 4 must be applied throughout the fabric with any lodes on the fabric released.

  Which configuration set meets these requirements?

  A. port-security activate vsan 4 no port-security auto-learn vsan 4 port-security allocate port-security commit vsan 4

  B. port-security activate vsan 4 force port-security auto-learn vsan 4 port-security distribute port-security commit

  C. port-security activate vsan 4 port-security manual-learn vsan 4 port-security allocate port-security commit

  D. port-security activate vsan 4 force no port-security auto-learn vsan 4 port-security distribute port-security commit vsan 4

  Correct Answer: D

• Question 313:

  An engineer must migrate a Cisco UCS C-Series server from Cisco SingleConnect to direct integration mode. The Cisco UCS Manager Rack Server Discovery Policy and Rack Management Connection Policy are set to immediate and Auto-Acknowledge. Which set of steps accomplishes this task?

  A. Disconnect the cables from the FEX. Connect the cables to server ports on the fabric interconnect. Reacknowledge the server.

  B. Disconnect the cables from the FEX. Connect the cables to appliance ports on the fabric interconnect. Reacknowledge the server.

  C. Disconnect the cables from the FEX. Connect the cables to server ports on the fabric interconnect. Reset the Cisco IMC of the server.

  D. Disconnect the cables from the FEX. Connect the cables to appliance ports on the fabric interconnect. Reset the Cisco IMC of the server.

  Correct Answer: A

• Question 314:

  Which two protocols are used by the NFSv4 protocol? (Choose two.)

  A. FCP

  B. TCP

  C. UDP

  D. Ethernet

  E. IP

  Correct Answer: BE

• Question 315:

  Refer to the exhibit.



  The ASA 1 acts as a Layer 3 gateway for all servers. The servers lose the gateway connectivity when the vPC peer links go down and the vPC keepalive remains up. Which action improves the high availability in the network?

  A. Create a static port channel with two links from each firewall to the switch

  B. Activate the vPC orphan-port suspend feature on the switch ports connected to the firewall

  C. Implement the IP reoVect feature on the vPC devices

  D. Enable the vPC peer gateway feature on the vPC devices

  Correct Answer: B

• Question 316:

  An engineer mus! configure the remote SSH management connectivity for Cisco Nexus 9000 Series Switches to meet these requirements The connectivity must be permitted from a jump host with an IP address of 10 10.10 10/24 All switches must be permitted to connect via SSH to other devices from the subnet of 10 .20.20.0/24 Which configuration set accomplishes these requirements?



  A. Option A

  B. Option B

  C. Option C

  D. Option D

  Correct Answer: B

• Question 317:

  Which two actions must be taken to directly connect a Fibre Channel storage array to a Cisco UCS domain? (Choose two.)

  A. Configure a new VSAN

  B. Create a new vHBA dedicated to the storage array

  C. Configure a Fibre Channel port channel

  D. Create a Storage Connection Policy

  E. Configure the Fibre Channel poet as a Fibre Channel storage port

  Correct Answer: AE

• Question 318:

  An engineer performs a Cisco UCS C480 ML M5 installation from a Cisco UCS Manager As a part of the design the server must perform an iSCSI bool from the storage array. Which configuration must be performed in the SAN settings in the root organization to satisfy that condition?

  A. Implement a WWPN pool

  B. Create a virtual iSCSI vNIC

  C. Enable a host SAN pool

  D. Create an IQN suffix pool

  Correct Answer: D

• Question 319:

  An engineer must affirm the identity of the Cisco UCS Manager after a valid CA-signed keyring for HTTPS access is created. Which action completes the configuration?

  A. Set Cipher Suite Mode

  B. Create a trusted point

  C. Implement SSLv3

  D. Enable TLSv1.2

  Correct Answer: B

• Question 320:

  Which component is excluded by default from the host firmware package?

  A. network interface controller

  B. board controller

  C. storage controller

  D. local disk

  Correct Answer: D
