Cisco CCNP Data Center 350-601 Questions & Answers

• Question 351:

  An engineer must configure OSPFv2 connectivity between a pair of Cisco Nexus switches. The connection between the switches must meet these requirements:

  1.

  Use unicast for updates.

  2.

  Use decentralized communication of updates.

  3.

  Full adjacency between switches.

  Which configuration is needed to meet these requirements?

  A. filter list between the neighbors

  B. stub area between the neighbors

  C. virtual link between the neighbors

  D. interface with a type of p2p network

  Correct Answer: A

• Question 352:

  An infrastructure architect is analyzing the deployment type for an application. Several companies must be able to operate the application environment and integrate it with a third-party protocol. The development team also must have maximum control over their development environment, including the operating system used, Python interpreter, and corresponding libraries. Which cloud deployment solution meets these requirements?

  A. private cloud Platform as a Service

  B. public cloud Storage as a Service

  C. hybrid cloud Software as a Service

  D. community cloud Infrastructure as a Service

  Correct Answer: D

• Question 353:

  An engineer is performing an ISSU upgrade on the Cisco MDS 9000 Series Switch. What is the impact on the control plane of the switch?

  A. It is down for less than 80 seconds.

  B. It remains down for more than 80 seconds but less than 140 seconds.

  C. It remains down until the next reboot.

  D. It remains up throughout the update.

  Correct Answer: A

• Question 354:

  An engineer must implement a disaster recovery policy for the Cisco UCS infrastructure. The solution must meet these criteria:

  1.

  The Recovery Point Objective must be 48 hours.

  2.

  The backup must use encrypted transmission.

  3.

  The Recovery Time Objective must be 4 hours.

  Which configuration set must be used in the scheduled backup to meet these requirements?

  A. Protocol: FTP Schedule: Bi-Weekly

  B. Protocol: SFTP Schedule: Weekly

  C. Protocol: TFTP Schedule: Bi-Weekly

  D. Protocol: SCP Schedule: Daily

  Correct Answer: D

• Question 355:

  Refer to the exhibit.



  What happens to the broadcast traffic when it reaches aggregation switches?

  A. Agg-2 switch receives broadcast packets and stops forwarding to the peer link on Agg-1 switch.

  B. Agg-1 switch prevents broadcast packets received on the vPC peer link from exiting the switch on ports Eth2/4 and Eth2/5.

  C. Agg-1 and Agg-2 switches receive broadcast packets and does not forward them to the peer link or the port channel.

  D. Only Agg-1 switch receives broadcast packets and does not forward to the peer link on Agg-2 switch.

  Correct Answer: B

  Duplicate Frames Prevention in vPC One of the most important forwarding rules for vPC is that a frame that enters the vPC peer switch from the peer link cannot exit the switch from a vPC member port.Figure shows switch-es 3 and 4 connected to 5k01 and 5k02 with vPCs Po51 and Po52. If one of the hosts connected to switch 4 sends either an unknown unicast or a broadcast, this traffic may get hashed to port eth2/2 on PortChannel 52. 5k02 receives the broadcast and needs to forward it to the peer link for the potential orphan ports on 5k01 to receive it. Upon receiving the broadcast, 5k01 detects that this frame is coming from the vPC peer link. Therefore, it does not forward it to port 2/9 or 2/10; if it did, a duplicate frame on switch 3 or 4, respectively, would be created. If a host on switch 4 sends a broadcast, 5k02 will correctly forward it to Po51 on port 2/9 and place it on the peer link. 5k01 will prevent this broadcast frame from exiting onto port 2/9 or 2/10 because this frame entered 5k01 from a vPC peer link. Should eth2/2 on switch 3 go down, port 2/9 on 5k01 would become an orphan port and as a result will receive traffic that traverses the peer link.



• Question 356:

  Which statement describes the rolling EPLD upgrade on a Cisco MDS 9000 Series Switch?

  A. The standby supervisor module is capable of performing the upgrade.

  B. Only the modules that are being upgraded are disrupted.

  C. All modules on the switch are disrupted.

  D. An EPLD upgrade is nondisruptive.

  Correct Answer: B

• Question 357:

  Which two statements describe the process of performing an EPLD upgrade on a Cisco MDS 9000 Series Switch? (Choose two.)

  A. The upgrade is performed from the standby supervisor module.

  B. The upgrade process disrupts only the module that is being upgraded.

  C. The upgrade is performed on the active supervisor.

  D. If an upgrade is interrupted, the upgrade continues after a connection is restored.

  E. Modules must be online to be upgraded.

  Correct Answer: AB

• Question 358:

  Refer to the exhibit.



  A network engineer must configure port E1/31-32 to forward only storage server traffic of VLAN 200 on Cisco fabric interconnects A and B. Port E1/31-32 is not reserved for any other traffic. Which port type must be configured to accomplish this goal?

  A. FCoE storage

  B. uplink

  C. unified uplink

  D. FCoE uplink

  Correct Answer: D

• Question 359:

  An engineer must configure RBAC in Cisco UCS Manager in an existing data center environment.

  Which two roles are suitable for configuring LAN connectivity policies? (Choose two.)

  A. server-profile

  B. network-admin

  C. operations

  D. enable

  E. admin

  Correct Answer: BE

• Question 360:

  An engineer must implement the FCoE on the Cisco Nexus 9000 Series Switch-based infrastructure. The deployment will contain dual-homed fabric extenders and must support jumbo frames with port channels. Which two sets of actions complete the configuration? (Choose two.)

  A. Create a virtual Fibre Channel Interface. Bind vFC to physical interface.

  B. Configure the interface with mtu 9516. Disable the feature NPIV.

  C. Create a dedicated VSAN for FEX. Bind VSAN to FEX uplinks.

  D. Execute fcoe enable-fex. Configure FEX uplinks with mtu 9216.

  E. Create a FCoE switch profile. Enable config sync.

  Correct Answer: AD
