Cisco CCNP Collaboration 350-801 Questions & Answers

• Question 311:

  Refer to the exhibit.



  IP phone A makes a call to IP phone B and RTP voice stream is successfully established between the endpoints. What option describes how to accomplish this call on phones with incompatible IP addressing versions?

  A. Set common device configuration to IPv4 and IPv6

  B. Set IP addressing mode preference for signalling to IPv4

  C. Assign a media resource group with available MTPs

  D. Enable alternative network address types

  Correct Answer: C

• Question 312:

  Which capability is supported by Cisco Discovery Protocol but not by LLDP-MED?

  A. LAN speed and duplex discovery

  B. network policy discovery

  C. location identification discovery

  D. power discovery

  E. trust extension

  Correct Answer: E

  Cisco Discovery Protocol provides an additional capability not found in LLDP-MED that allows the switch to extend trust to the phone. In this case, the phone is now trusted to mark the packets received on the PC port accordingly. This feature can be used to off-load the switch because now it does not need to police the information being received from the phone.

• Question 313:

  Which three Cisco Unity Connection call handler greetings can be overridden by the internal greeting? (Choose three.)

  A. holiday

  B. alternate

  C. error

  D. busy

  E. closed

  F. standard

  Correct Answer: AEF

  This greeting overrides the Standard, Closed, and Holiday greetings but only for internal callers or users defined in Cisco Unity Connection.Because the mentioned three greetings are defined for externals users.

• Question 314:

  How is Video Call Traffic Class defined on Cisco Unified CM for Enhanced Location CAC bandwidth deductions?

  A. On each device's configuration page

  B. On Device Profile page

  C. On SIP Profile configuration page

  D. On Location configuration page

  E. On each device or Device Pool's configuration page

  Correct Answer: D

• Question 315:

  Refer to the exhibit.



  Assume that the bottom logical partition policy entry in Cisco Unified Communications Manager was provisioned last.

  How is the call treated when an IP phone in the Bangalore GeoLocation places a call to a MGCP gateway with FXS ports in the San Jose GeoLocation?

  A. The call is denied because the last added logical partition policy takes precedence when multiple matches exist.

  B. The call is allowed because the first listed logical partition policy takes precedence when multiple matches exist.

  C. The call is denied because the call flow matches neither policy entries.

  D. The call is allowed because the call flow matches neither policy entries.

  E. The call is allowed because only the top policy entry matches the call flow.

  Correct Answer: A

• Question 316:

  In a Cisco Unified Communications Manager design where +E.164 destinations are populated in directory entries, which call routing practice is critical to prevent unnecessary toll charges caused by internal calls routed through the PSTN?

  A. forced on-net routing

  B. automated alternate routing

  C. forced authorization codes

  D. client matter codes

  E. tail-end hop-off

  Correct Answer: A

• Question 317:

  When deploying Mobile and Remote Access (MRA), which two SAN entries are mandatory in the Expressway Series certificates for secure phone registration? (Choose two.)

  A. Unified CM Phone security profile name in Expressway-C certificate

  B. Unified CM registration domain in Expressway-C certificate

  C. Unified CM Phone security profile name in Expressway-E certificate

  D. IM and Presence Chat node alias in Expressway-C certificate

  E. IM and Presence Chat node alias in Expressway-E certificate

  F. Unified CM registration domain in Expressway-E certificate

  Correct Answer: AF

• Question 318:

  Which four requirements are mandatory to enable a mixed mode Cisco Unified CM cluster? (Choose four.)

  A. Cisco CTL Provider Service activated and enabled

  B. Cisco Certificate Authority Proxy Function activated and enabled

  C. Cisco Trust Verification activated and enabled

  D. Cisco CTL client

  E. a minimum of one USB e-token

  F. a minimum of two USB e-token

  G. a minimum of one soft e-token

  Correct Answer: ABDF

• Question 319:

  Which two descriptions of TFTP option 66 and 150 for Cisco IP phones are true? (Choose two.)

  A. Option 150 supports multiple entries of TFTP server IP addresses, but option 66 supports only one of TFTP server DNS names.

  B. Option 150 supports only TFTP server IP addresses, but option 66 supports only TFTP server DNS names.

  C. Option 150 supports multiple entries of TFTP server IP addresses, but option 66 supports only one entry of either TFTP server IP address or DNS name.

  D. Option 66 is Cisco proprietary, but option 150 is standard-based.

  E. Option 150 is Cisco proprietary, but option 66 is standard-based.

  F. Option 150 and 66 are standard-based.

  Correct Answer: CE

• Question 320:

  Which message-handling behavior describes how Cisco Unity Connection Single Inbox works for Outlook users who do not have ViewMail installed?

  A. Cisco Unity Connection voice messages are treated as emails without a WAV file attachment.

  B. Cisco Unity Connection voice messages are treated as voice messages.

  C. Cisco Unity Connection voice messages are treated as emails with a WAV file attachment.

  D. Cisco Unity Connection adds a Voice Outbox folder to the Outlook mailbox.

  E. Replies to Cisco Unity Connection voice messages are sent to Exchange as well as the Cisco Unity Connection mailbox for the recipient.

  Correct Answer: C

  Cisco unity here acts as a imap server for yhe outlook user who don't have view mail installed so user send their request as an imap client and unity will revert back with email and wav file attached to play.
