Cisco CCNP Collaboration 350-801 Questions & Answers

• Question 321:

  A Cisco collaboration engineer is troubleshooting unexpected SIP call disconnect. Which three responses corresponding to the 5xx range? (Choose Three)

  A. Forbidden

  B. Unauthorized

  C. Request timeout

  D. Service unavailable

  E. Bad gateway

  F. Internal server error

  Correct Answer: DEF

• Question 322:

  Which statement describes the Maximum Serving Count service parameter of the Cisco TFTP service on Cisco Unified Communications Manager?

  A. It specifies the maximum number of files in the TFTP server disk storage.

  B. It specifies the maximum number of TFTP client requests to accept and to serve files at a given time.

  C. It specifies the maximum file support by the Cisco TFTP service.

  D. It specifies the maximum file counts, in cache as well as in disk, that are supported by the Cisco TFTP service.

  E. It specifies the maximum number of TFTP client requests to accept and to serve files in a 120-minute window.

  Correct Answer: B

• Question 323:

  Which Cisco Unified CM service is installed by default and authenticates certificates on behalf of IP phones and other endpoints?

  A. Cisco CTL Provider

  B. Cisco Certificate Authority Proxy Function

  C. Cisco Trust Verification

  D. Cisco CallManager

  E. Cisco TFTP

  Correct Answer: C

• Question 324:

  A Cisco collaboration engineer is troubleshooting unexpected SIP call disconnects. Which three responses correspond to the 5xx range (Chose three).

  A. Server timeout

  B. Bad request

  C. Temporarily unavailable

  D. Service unavailable

  E. Forbidden

  F. Version not supported

  Correct Answer: ADF

• Question 325:

  A Cisco Unity Connection administrator receives a name change request from a voice-mail user, whose Cisco Unity Connection user account was imported from Cisco Unified Communications Manager. What should the administrator do to execute this change?

  A. Change the user data in the Cisco Unity Connection administration page, then use the Synch User page in Cisco Unity Connection administration to push the change to Cisco Unified Communications Manager.

  B. Change the user data in the Cisco Unified Communications Manager administration page, then use the Synch User page in Cisco Unity Connection administration to pull the changes from Cisco Unified CM.

  C. Change the user data in the Cisco Unified Communications Manager administration page, then use the Synch User page in Cisco Unified CM administration to push the change to Cisco Unity Connection.

  D. Change the user profile from Imported to Local on Cisco Unity Connection Administration, then edit the data locally on Cisco Unity Connection.

  E. Change the user data in Cisco Unity Connection and Cisco Unified Communications Manager separately.

  Correct Answer: B

  As we can see user are getting synch from call manager so we first have to change the details of user on call manager so that user will synch the changes from call manager.

• Question 326:

  Which design restriction applies to Cisco Unified Communications Manager Session Management Edition clustering over the WAN deployment with extended round-trip times in Cisco Unified CM 9.1 and later releases?

  A. SIP and H.323 intercluster trunks are supported.

  B. Only SIP trunk is supported.

  C. SIP trunks and H.323 gateways are supported.

  D. A minimum of 1.544 Mb/s bandwidth is required for all traffic between any two nodes in the cluster.

  E. Only RSVP agents can be configured and registered to the SME cluster as media resources.

  Correct Answer: B

• Question 327:

  Which wildcard must an engineer configure to match a whole domain in SIP route patterns?

  A. .

  B. !

  C. @

  D. *

  Correct Answer: D

  Reference: https://www.cisco.com/c/en/us/td/docs/voice_ip_comm/cucm/admin/10_0_1/ccmcfg/CUCM_BK_C95ABA82_00_admin-guide-100/CUCM_BK_C95ABA82_00_admin-guide-100_chapter_0100111.html

• Question 328:

  Refer to the exhibit.



  Which option describes the security encryption status of this active call on a Cisco IP phone?

  A. unencrypted call signaling and media

  B. encrypted call signaling but unencrypted call media

  C. encrypted call media but unencrypted call signaling

  D. encrypted call signaling and media

  E. Not enough information provided to answer this question.

  Correct Answer: D

• Question 329:

  An engineer must configure an MGCP gateway and register it to Cisco Unified Communications Manager. Which prerequisite must be met before applying the gateway commands to enable MGCP?

  A. The MGCP gateway and the Cisco Unified CM must be able to communicate aver ports 5060 and 5061.

  B. Cisco Unified CM and the MGCP gateway must utilize the SIP OPTIONS ping feature to monitor status.

  C. The MGCP gateway must have voice service VoIP configured.

  D. The MGCP gateway and the Cisco Unified CM must be able to communicate over ports 2427, 2428, and 2727.

  Correct Answer: D

  Reference: https://www.cisco.com/c/en/us/td/docs/ios/voice/cminterop/configuration/guide/12_4t/vc_12_4t_book/vc_ucm_mgcp_gw.html

• Question 330:

  Which description of the function of call handlers in Cisco Unity Connection is true?

  A. They answer calls, take messages, and provide menus of options.

  B. They provide access to a corporate directory by playing an audio list that users and outside callers use to reach users and leave messages.

  C. They collect information from callers by playing a series of questions and recording the answers.

  D. They control outgoing calls by allowing you to specify the numbers that Cisco Unity Connection can dial to transfer calls, notify users of messages, and deliver faxes.

  Correct Answer: A

  Reference: https://www.cisco.com/c/en/us/td/docs/voice_ip_comm/connection/10x/administration/guide/10xcucsagx/10xcucsag080.html
