HP HP ASE HP0-S33 Questions & Answers

• Question 51:

  Which HP tool allows you to generate a full report that can be sent to customer service for telephone support?

  A. IML

  B. ACU

  C. SIM

  D. ADU

  Correct Answer: D

  http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00687518/c00687518.pdf (pag 16)

  Array Diagnostics Utility ADU is an in-depth diagnostic and reporting utility for all Smart Array controllers. The ADU quickly identifies problems such as incorrect versions of firmware, improperly installed drives, inappropriate error rates, and failed batteries on the array accelerator board. The ADU displays a detailed analysis of the system configuration. If the cause is not apparent, the ADU can generate a full report for administrators to fax or e-mail to HP customer service for phone support.

• Question 52:

  Which RBSU setting should be changed for low latency and maximum performance?

  A. Configure for no C-states

  B. Enable turbo-boost

  C. Enable iLO performance monitoring

  D. Disable power regulator

  Correct Answer: A

• Question 53:

  You configured disk thresholds for all servers running Windows Server 2008 R2. You want HP SIM to react by running a script that will delete all IE temporary files on the server that reports problems with the available capacity on the drive. What do you have to configure from the HP SIM level to achieve this?

  A. Configure the Single Sign On feature for all the servers that should be covered that script.

  B. Establish a trust relationship between HP SIM and all servers covered by that script, and apply the Insight Control licenses.

  C. Create a custom command that will delete temporary files and configure an automatic event handling task to run this script when a specific event occurs.

  D. Import the HP SIM certificate to the HP System Management homepage for all of the servers that should be covered by that script and configure SNMP security to allow remote command execution.

  Correct Answer: C

• Question 54:

  What can you configure with the BladeSystem Insight Display on a c7000 enclosure? (Select three)

  A. Rack name

  B. Power mode

  C. Number of fans installed

  D. OA1 IP address

  E. Blade name

  F. Midplane serial number

  Correct Answer: ABD

  Reference: http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00698534/c00698534.pdf (page 13)



• Question 55:

  Which Advanced Memory Protection configuration allows a system to survive the complete of two DRAM devices?

  A. Lockstep mode with RDIMMs

  B. Online Spare Memory mode

  C. Lockstep mode with UDIMMs

  D. Advanced ECC mode with UDIMMs

  Correct Answer: A

  http://h20000.www2.hp.com/bizsupport/TechSupport/Document.jsp? lang=esandcc=lamerica_nsc_cnt_amerandtaskId=115andprodSeriesId=5177937andprodTypeId=15351 andobjectID=c03250296

  The server also can operate in independent channel mode or combined channel mode (lockstep). When running in lockstep mode, user gains reliability in one of two ways:

  If running with UDIMMs (built with x8 DRAM devices), the system can survive a complete DRAM failure (SDDC). In independent channel mode, this failure would be an uncorrectable error.

  If running with RDIMM (built with x4 DRAM devices), the system can survive the complete failure of two DRAM devices (DDDC). Running in independent mode, the server can only survive the complete failure of a Single DRAM Device

  (SDDC).

• Question 56:

  A customer wants the latest Ultrium technology solution integrated into the company's BladeSystem c- Class enclosures. What is the correct tape solution?

  A. HP StorageWorks SB3000c

  B. HP StorageWorks SB920c

  C. HP StorageWorks Ultrium 1840b

  D. HP StorageWorks Ultrium 960c

  Correct Answer: A

  http://h18000.www1.hp.com/products/quickspecs/12729_na/12729_na.pdf

• Question 57:

  How many server connect into a 4U HP ProLiant S6500 chassis?

  A. 4 x HP ProLiant SL 165s G7

  B. 4 x HP BL860c i2

  C. 4 x BL460 G7

  D. 8 x HP ProLiant SL165s G7

  Correct Answer: A

  Reference:

  http://www.pcconnection.com/IPA/PM/Brands/AMD/Servers/~/media/F787C33A144D4E0DA804D2092 (page 4, HP proliant sl165s G7, first bullet)

  A6E735E.pdf?v=2

  HP ProLiant SL165s G7

  The HP ProLiant SL165s G7 server is part of the HP ProLiant SL6500 family, optimized for scale-out customers and designed to greatly reduce costs, maximize power efficiency (by sharing power supplies and fans), and maintain total

  flexibility. The HP ProLiant SL165s G7 is optimized for applications needing large amounts of memory and I/O expansion such as scale- out, Web 2.0, and high-performance computing (HPC) environments. ?Form factor: 2P, 1U full-width tray

  node. Four independent HP ProLiant SL165s G7 servers go into the 4U HP ProLiant s6500 chassis

• Question 58:

  You are designing a new multi-site data center. A key requirement for storage is to start with a small solution and include the ability to increase capacity and performance as needed. Which storage solution has the opportunity to start with 2 nodes, scaling up to 32 nodes as a single solution?

  A. HP 3PAR T800/P10000

  B. HP P2000

  C. HP P6000 EVA

  D. HP P4000

  Correct Answer: D

• Question 59:

  A consultant must provide a UPS solution to support the load requirement of a server solution being delivered. What is the recommended tool to use to provide the correct UPS solution?

  A. HP Rack and Power Sizer (upssizer.com)

  B. HP Value UPS Manager

  C. HP Rack and Power manager

  D. HP Power Advisor

  Correct Answer: A

  Reference: http://h18004.www1.hp.com/products/solutions/power/index.html

• Question 60:

  What is one of the new feature of HP ProLiant Gen8 servers?

  A. Virtual connect

  B. FlexPod adapters

  C. Smart Storage

  D. SmartStart

  Correct Answer: C
