VMware VMware Certifications VCP-510 Questions & Answers

• Question 21:

  Networking policies, such as traffic shaping and security, can be configured on the following vSphere elements:

  A. On the physical network interface and the vSwitch

  B. On the port group and the physical network interface

  C. On the port group and the vSwitch

  D. On the vSwitch and the attached virtual machine

  Correct Answer: C

• Question 22:

  The vSwitch or vSwitch port group policy setting that allows a virtual machine to listen to traffic other than that which is specifically destined for the given VM is:

  A. MAC Address Changes

  B. Promiscuous Mode

  C. Forged Transmits

  D. Traffic Shaping

  Correct Answer: B

• Question 23:

  Which of the following describes the default behavior of uplinks added to a vNetwork Standard Switch:

  A. All uplinks are active

  B. The first uplink is active, additional uplinks are standby

  C. The first uplink is active, additional uplinks are unused

  D. Only one uplink can be attached to a virtual switch

  Correct Answer: A

• Question 24:

  Assuming VLANs are not configured, which of the following is true about traffic from a virtual machine connected to a port group on a vNetwork Standard Switch with no uplinks?

  A. Virtual machines in any port group on the virtual switch can receive the traffic.

  B. The virtual switch will drop the packets if no uplink is present.

  C. Virtual machines on any virtual switch on the same ESX Server can receive the traffic.

  D. Only virtual machines in the same port group on the virtual switch can receive the traffic.

  Correct Answer: A

• Question 25:

  Which of the following are valid use cases for VMware Fault Tolerance (Choose Three)?

  A. An administrator wants to provide continuous availability if a business critical application fails

  B. An administrator wants to provide on-demand fault tolerance for a virtual machine during a critical operation

  C. An administrator wants application high availability for applications that are not cluster aware

  D. An administrator wants to provide continuous availability if a critical hardware component fails

  E. An administrator wants to provide fault tolerance for one or more physical servers

  Correct Answer: BCD

• Question 26:

  Users are complaining that a Windows application server virtual machine configured with 1GB RAM is not performing satisfactorily. The virtual machine is in a fully automated DRS cluster. An administrator opens the Performance tab for the

  guest virtual machine and adds the counters for Memory Ballooned and Memory Swapped in MB. The performance chart displays a value of 0 for Memory Ballooned and 240 for Memory Swapped.

  Which action should be taken?

  A. Install VMware Tools into the virtual machine.

  B. Adjust Mem.CtlMaxPercent to read 75.

  C. Migrate the virtual machine to another host.

  D. Add memory to the virtual machine.

  Correct Answer: A

• Question 27:

  The VMware vCenter Server Appliance offers many features of the Windows application version.

  Which of the following features is only available on the Windows application version of vCenter?

  A. Host Profiles

  B. Template and clone customization

  C. Active Directory authentication

  D. Linked Mode

  Correct Answer: D

• Question 28:

  When comparing software iSCSI initiators with independent hardware initiators, what are the additional CHAP security levels available for a software implementation? (Choose two.)

  A. Do not use CHAP unless required by target

  B. Use CHAP

  C. Use CHAP unless prohibited by target

  D. Do not use CHAP

  Correct Answer: AB

• Question 29:

  While verifying host connectivity to datastores using topology maps, the administrator sees that one of the hosts in a DRS/HA cluster is framed by a pale green circle. What does this indicate?

  A. The host has a vMotion validation issue.

  B. The host has a low workload.

  C. The host has a CPU incompatibility.

  D. The host is heavily utilized.

  Correct Answer: D

• Question 30:

  An administrator receives a report that a failover event has occured on a storage device. Following the event, multiple Microsoft Windows based virtual machines experienced blue screen errors. Only Microsoft Windows based virtual machines were affected. What can be done to ensure that these virtual machines remain up and running?

  A. Change the Microsoft Windows guest operating system disk timeout from 30 seconds to 60 seconds.

  B. Change the Microsoft Windows guest operating system disk timeout from 60 seconds to 90 seconds.

  C. Ensure that the Windows VMs are using LSI logic virtual SCSI controllers.

  D. Ensure that the Windows VMs are using Buslogic virtual SCSI controllers.

  Correct Answer: A
