HP HP Certifications HPE6-A44 Questions & Answers

• Question 161:

  A VIA client tries to initially connect to corporate office controller through an intermediate firewall. However, the VPN connection fails. The administrator examines the firewall rules and determines that rules for UDP 4500 and UDP 500 are configured.

  Which additional protocol must be allowed in the firewall rules to resolve this connection failure?

  A. TCP 22

  B. TCP 443

  C. UDP 8200

  D. ESP

  Correct Answer: D

• Question 162:

  An administrator supports a cluster of four Aruba Mobility Controllers (MCs) with management addresses of 10.1.100.101, 10.1.100.102, 10.1.100.103, and 10.1.274.426. The administrator accesses an AP associated with this cluster, reboots it and accesses apboot mode. The administrator executes the printenv command. Which AP parameter contains the IP addresses of the cluster members that the AP should use to connect to the cluster?

  A. Nodelist

  B. Servername

  C. Master_ip

  D. Cfg_lms

  Correct Answer: A

  Reference:

  https://www.arubanetworks.com/assets/atmosphere/2018-Airheads/Fundamentals%20Guide%20-%

  20ArubaOS%208%20Fundamentals.pdf

  Page 89

• Question 163:

  Refer to the exhibit.



  What can be determined from the command output shown in the exhibit?

  A. The synchronized data is protected by VRRP.

  B. The command was executed on the standby Mobility Master (MM).

  C. The synchronization period is at its default value.

  D. The other Mobility Master (MM) is the active license server.

  Correct Answer: D

• Question 164:

  Refer to the exhibit.



  An administrator supports a RAP at a branch office shown in the exhibit. The company has one Mobility Controller (MC) at the Primary DMZ site and one at the Secondary DMZ site. The RAP is configured to connect to only the MC at the Primary DMZ site. A network outage with the ISP at the Primary DMX site causes the RAP to reboot. Upon reboot, the RAP cannot build a tunnel to the Secondary DMZ site MC because the administrator forgot to add the Second LMS IP address to the AP Group configuration. Once the RAP can successfully connect, the administrator can add the Secondary DMZ MC as a backup LMS to fix the AP Group.

  What should the administrator implement to allow the RAP to connect to the MC at the Secondary DMZ site while the outage at the primary site persists?

  A. Dynamic discovery through DHCP Option 43

  B. Static configuration from apboot mode

  C. Dynamic discovery through DHCP Option 60

  D. Dynamic discovery through multicast ADP

  Correct Answer: A

• Question 165:

  An administrator adds local administrative accounts to manage the Aruba Mobility Controllers (MCs). Which role should be assigned to an administrator who needs to only generate reports and monitor WLANS and ports?

  A. Location-api-management

  B. Network-operations

  C. Root

  D. AP-provisioning

  Correct Answer: B
