OMG OMG Certifications OMG-OCUP2-INT200 Questions & Answers

• Question 51:

  What situation results from an Apply Function Action?

  A. reads objects and produces output values

  B. produces output values

  C. writes objects and produces output values

  D. reads objects, write objects, and produces output values

  E. performs any set of UML actions

  Correct Answer: B

• Question 52:

  What is wrong with the Sale instance diagram shown in the exhibit?



  A. Buyer instance name is missing.

  B. Link name should be underlined.

  C. Sale instance name is missing.

  D. Link should be shown with a dashed line.

  E. Types of the buyer and seller parts are missing.

  Correct Answer: B

• Question 53:

  What value should insertAt be set to when adding a new value to the end of a 5-element ordered structural feature using an AddStructuralFeatureValueAction?

  A. any integer greater than 5

  B. -1

  C. infinity

  D. 0

  Correct Answer: C

• Question 54:

  What elements can have variables in activity diagrams?

  A. actions

  B. structured edges

  C. partitions

  D. activities

  E. structured nodes

  Correct Answer: E

• Question 55:

  In the exhibit, what is true about Mpar?



  A. There are legal traces that do not contain message q.

  B. Every trace contains all three messages.

  C. Receiving p must always precede receiving q.

  D. Sending p must always precede sending q.

  Correct Answer: B

• Question 56:

  What does a conditional node consist of?

  A. clauses

  B. guards

  C. parameters

  D. body Part nodes

  E. behaviors

  F. partitions

  Correct Answer: A

• Question 57:

  What is true for part decomposition in interaction diagrams?

  A. cannot be reused as decomposition from another lifeline

  B. must match the constructs of the decomposed lifeline

  C. must always be owned by the same interaction as the decomposed lifeline

  D. always refers to methods of the decomposed lifeline

  Correct Answer: B

• Question 58:

  What is NOT true of a CreateObjectAction? (Choose two.)

  A. output pin has multiplicity [1..*]

  B. classifier cannot be an association class

  C. output pin has multiplicity [1..1]

  D. classifier must be abstract

  E. classifier cannot be abstract

  F. type of the output pin is the classifier

  Correct Answer: AD

• Question 59:

  Which relationships would make the model in the exhibit ill-formed?



  A. Special Order and Order are related to each other via a dependency.

  B. Special Order and order are related to each other via an association.

  C. Order is a subtype of Special Order.

  D. Special Order is a subtype of Order.

  Correct Answer: C

• Question 60:

  What does the composite structure exhibit show?



  A. The diagram is not valid.

  B. Requests for behavioral features of interface F through ports p1a nd p2 will always result in the same behavior.

  C. The two F interfaces must come from different packages.

  D. Requests for behavioral features of interface F through

  Correct Answer: D
