Cisco CCNP Data Center 350-601 Questions & Answers

• Question 61:

  Refer to the exhibit. An engineer created a VRF called “Sigtran” using Terraform resource “aci_vrf” identified by “Signaling” and the bridge domain called “App”.



  Which argument reference must be used to map the bridge domain to the “Sigtran” VRF?

  A. aci_vrf.Signaling.id

  B. aci_vrf.App.id

  C. aci_vrf.Sigtran.id

  D. aci_vrf.PROD.id

  Correct Answer: A

• Question 62:

  Refer to the exhibit. An engineer uses Python in Cisco NX-OS guest shell to retrieve the configuration of the EIGRP ASN on interface eth1/1. The engineer has written this script:



  >>> import json >>> from cli import*

  Which command set must be used to retrieve the value of the 'asn' key?

  A. >>> output = json.loads(clid('show ip eigrp neighbors')) >>> output['TABLE_asn']['ROW_asn']['asn']

  B. >>> output = json.dumps(clid('show ip eigrp neighbors')) >>> output['TABLE_asn']['ROW_asn']['asn']

  C. >>> output = json.dumps(clid('show ip eigrp neighbors')) >>> output['asn']

  D. >>> output = json.loads(clid('show ip eigrp neighbors')) >>> output['asn']

  Correct Answer: A

• Question 63:

  Refer to the exhibit.



  What happens to the VRRP configuration when the router SW9621-2 becomes operational?



  A. The SW9621-2 router becomes a new active master.

  B. The SW9621-1 router becomes a new active master after 3 seconds.

  C. The SW9621-1 router remains an active master.

  D. The SW9621-2 router becomes an active master after 3 seconds.

  Correct Answer: A

• Question 64:

  Refer to the exhibit.



  An engineer must access a Cisco UCS C-Series server KVM from a remote location. The engineer must use the out-of-band interface to access the KYM. Which configuration set meets these requirements?

  A. NIC mode: Shared LOM VLAN ID: 100

  B. NIC mode: Dedicated VLAN ID: 101

  C. NIC mode: Dedicated VLAN state: Disabled

  D. NIC mode: Shared LOM VLAN state: Disabled

  Correct Answer: C

• Question 65:

  Refer to the exhibit.



  An engineer configures an FCoE connection between a Cisco UCS and a Cisco Nexus 9000 Series Switch. The UCS FI-A connects to the Nexus switch using interface e1/12. All relevant configurations have been completed on the Nexus switch to support FCoE deployment. Which action must be taken on Cisco UCS Manager to complete the configuration?

  A. Trunk VLAN 500 on interface e1/12.

  B. Create a Virtual Fibre Channel Interface.

  C. Change the Transport Type to FCoE.

  D. Configure an FCoE uplink interface.

  Correct Answer: D

• Question 66:

  An engineer must configure a Fibre Channel port channel on a Cisco Nexus 9000 Series Switch. The configuration must meet these requirements:

  1.

  A port-channel protocol negotiation is performed with the peer ports.

  2.

  The trunk mode must be explicitly configured for the interfaces.

  3.

  VSANs from 10 to 20 must be allowed.

  Which command set configures the devices to meet the requirements?



  A. Option A

  B. Option B

  C. Option C

  D. Option D

  Correct Answer: C

  A port-channel protocol negotiation is performed with the peer ports. channel mode active plus san-port-channel for Cisco 9000

• Question 67:

  Refer to the exhibit. An engineer must configure port security on the Cisco Nexus 5000 Series Switch that meets these requirements:



  1.

  Port security must be applied on VSAN 10 only.

  2.

  NWWN 20:10:10:10:10:10:10:10 to log in through SAN port-channel 2.

  3.

  Any WWN must be allowed to log in through interfaces fc1/1, fc1/2, fc1/3.

  4.

  Auto learning must be disabled.

  Which command set satisfies these conditions?

  A. Nexus5K(config)# port-security database vsan 10 Nexus5K(config-port-security)# nwwn 20:10:10:10:10:10:10:10 interface san-port-channel 2 Nexus5K(config-port-security)# any wwn interface fc1/1-3 Nexus5K(config-port-security)# port-security commit vsan 10

  B. Nexus5K(config)# port-security activate vsan 10 no auto-learn Nexus5K(config)# port-security database vsan 10 Nexus5K(config-port-security)# nwwn 20:10:10:10:10:10:10:10 interface san-port-channel 2 Nexus5K(config-port-security)# any wwn interface fc1/1-3

  C. Nexus5K(config)# port-security database vsan 10 Nexus5K(config-port-security)# nwwn 20:01:01:01:01:01:01:01 interface san port-channel 5 Nexus5K(config-port-security)# any wwn interface fc1/1-3 Nexus5K(config)# port-security database diff active vsan 10

  D. Nexus5K(config)# port-security database vsan 10 Nexus5K(config-port-security)# nwwn 20:01:01:01:01:01:01:01 interface port-channel 5 Nexus5K(config-port-security)# any wwn interface fc1/1-3 Nexus5K(config)# port-security database diff active vsan 10

  Correct Answer: A

• Question 68:

  A network engineer an EPLD update on the fan modules of a Cisco Nexus 7000 series switch. What is the impact if "y is selected to continue?



  A. The switch is power cycled for the fan modules to start running the code and it is auto reloaded.

  B. The update is completed because it is nondisruptive and a power cycle is not required alter the upgrade.

  C. The switch is power cycled for the fan modules to start running the new code and prompts before each module is reloaded.

  D. The update does not complete successfully and the switch needs to power cycle.

  Correct Answer: B

• Question 69:

  An engineer must configure two Cisco Nexus 7000 series switches in the same data center to support OTV. Which command set completes the join interface configuration?





  A. Option A

  B. Option B

  C. Option C

  D. Option D

  Correct Answer: A

• Question 70:

  An engineer must perform a configuration backup of an existing Cisco UCS Manager environment. The backup file must contain all vNIC, vHBA, and service profile template settings. Also, the engineer must validate the backup before import and requires an XML output format. Which backup type must be used to meet these requirements?

  A. full state

  B. all configuration

  C. logical configuration

  D. system configuration

  Correct Answer: C
