Cisco CCNP Data Center 350-601 Questions & Answers

• Question 81:

  Which behavior defines streaming telemetry as a push model in Cisco devices?

  A. Monitoring clients are pulling data from the network to see real-time statistics

  B. JSON encoded telemetry data is transported using the gRPC protocol

  C. The network devices send data in JSON or GPB format to configured endpoints

  D. Events and network changes generate telemetry data

  Correct Answer: D

  https://developer.cisco.com/docs/ios-xe/#!streaming-telemetry-quick-start-guide/streaming-telemetry

• Question 82:

  A network engineer must perform a backup and restore of the Cisco Nexus 5000 Series Switch configuration. The backup must be made to an external backup server. The only protocol permitted between the Cisco Nexus switch and the backup server is UDP. The backup must be used when the current working configuration of the switch gets corrupted.

  Which set of steps must be taken to meet these requirements?

  A. 1 Perform a startup-config backup to an FTP server. 2 Copy startup-config in the boot flash to the running-config file

  B. 1 Perform a running-config backup to an SFTP server 2 Copy backup-config from the SFTP server to the running-config file

  C. 1 Perform a running-config backup to an SCP server 2 Copy running-config in the boot flash to the running-config file

  D. 1 Perform a startup-config backup to a TFTP server 2 Copy backup-config from the backup server to the running-config file

  Correct Answer: D

  TFTP is the only protocol that uses UDP. FTP, SFTP, and SCP use TCP.

• Question 83:

  What does this configuration create?



  A. three subnets within a bridge domain

  B. a CTX1 tenant

  C. an L3OUT-1 bridge domain

  D. two L3Out domains

  Correct Answer: A

• Question 84:

  Refer to the exhibit.



  A network engineer must monitor the traffic from the server on VLAN 80. All source traffic from the server must be captured on the monitoring device.

  Which configuration set meets these requirements?

  A. switch(config-monitor)# destination interface ethernet 1/1 switch(config-monitor)# source vlan 80

  B. switch(config-monitor)# destination interface ethernet 1/1 switch(config-monitor)# filter vlan 80

  C. switch(config-monitor)# destination interface ethernet 1/2 switch(config-monitor)# filter vlan 80 rx tx

  D. switch(config-monitor)# destination interface ethernet 1/2 switch(config-monitor)# source vlan 80 rx

  Correct Answer: A

• Question 85:

  A network engineer must configure a Fibre Channel port monitoring for the local port. The source port should be monitored in the ingress direction.

  Which configuration should be implemented to achieve this objective?

  A. interface fc1/15 switchport mode SD switchport speed 2000 no shutdown

  span session 1

  destination interface fc1/15

  source interface fc1/16 rx

  B. interface fc1/15 switchport mode switchport switchport speed 2000 no shutdown

  span session 1

  destination interface fc1/15

  source interface fc1/16 tx

  C. interface fc1/15 switchport mode fex-fabric switchport speed 2000 no shutdown

  span session 1

  destination interface fc1/15

  source interface fc1/16 rx

  D. interface fc1/15 switchport mode SD switchport speed 2000 no shutdown

  span session 1

  destination interface fc1/15

  source interface fc1/16 tx

  Correct Answer: A

• Question 86:

  Which value is missing in the field in the key called “msg” in this JSON response?



  A. Success

  B. Available

  C. Unavailable

  D. Drop

  Correct Answer: A

• Question 87:

  An engineer must perform an initial configuration of VXLAN and MP-BGP EVPN on the Cisco Nexus 9000 Series platform. The underlay must be OSPF, and the VTEP must run with distributed default gateway on a VLAN interface. Which command set must be applied to meet these requirements?

  A. NX9K(config)# feature nv overlay NX9K(config)# feature vn-segment-vlan-based NX9K(config)# feature bgp NX9K(config)# nv overlay-evpn NX9K(config)# feature ospf NX9K(config)# feature interface-vlan

  B. NX9K(config)# feature nv overlay NX9K(config)# feature bfd NX9K(config)# feature vn-segment-vlan-based NX9K(config)# nv overlay-evpn NX9K(config)# feature ngmvpn NX9K(config)# feature ospf

  C. NX9K(config)# feature nv overlay NX9K(config)# feature bfd NX9K(config)# feature fabric forwarding NX9K(config)# feature vn-segment-vlan-based NX9K(config)# nv overlay-evpn NX9K(config)# feature ospfv3

  D. NX9K(config)# feature nv overlay NX9K(config)# feature bgp NX9K(config)# feature bfd NX9K(config)# feature ngmvpn NX9K(config)# feature ospf

  Correct Answer: A

• Question 88:

  Which event is expected during direct upgrade of Cisco UCS Manager firmware?

  A. The I/O Module reboots immediately after the firmware is activated.

  B. All users logged in to the UCSM are logged out, and their sessions end.

  C. Data traffic is disrupted for a single fabric interconnect setup.

  D. IPMI polling is interrupted.

  Correct Answer: B

• Question 89:

  An engineer troubleshoots an Fibre Channel deployment on a Cisco MDS 9000 Series Switch. What does this output indicate about port channel 1?



  A. Port channel 1 is configured to be an ISL.

  B. Port channel 1 is configured to connect to an NPV switch.

  C. Port channel 1 is configured to connect to a host bus adapter.

  D. Port channel 1 is configured to connect to an NPIV switch.

  Correct Answer: B

• Question 90:

  What occurs when running the command install deactivate while a software maintenance upgrade is performed on a Cisco Nexus 9000 Series switch?

  A. The current set of packages is committed.

  B. The package is removed from the switch.

  C. The package features for the line card are disabled.

  D. The current upgrade stops.

  Correct Answer: C

  Reference: https://www.cisco.com/c/en/us/td/docs/switches/datacenter/nexus9000/sw/6-x/system_management/configuration/guide/b_Cisco_Nexus_9000_Series_NX-OS_System_Management_Configuration_Guide/ sm_smu.html#task_B8B0F5BA80BE41AEA93197F560665648
