HP ASE HP2-Z32 Questions & Answers

• Question 21:

  A company wants to allow layer 2 roaming between two aps what are requirements for layer 2 roaming?

  A. The aps must both support fast roaming

  B. The WLAN no both aps must have the same security settings

  C. The aps must support the same service set ID(SSID)

  D. The WLAN no both aps must be configured as open systems.

  E. The aps redios must support the same basic and supported rates.

  Correct Answer: C

• Question 22:

  A company needs a WLAN for its employees Network administrators are planning a non-access- controlled VSC that enforces WPA2 and 802.1x. The network administrators want to assign wireless clients to VLAN 10 in building 1 and to VLAN 20 in building 2.

  What is the proper design?

  A. Two VSCs each or which specifies a different egress VLAN

  B. One VSC that specifies two egress VLANs

  C. Two VSCs each of which specifies a different ingress VLAN

  D. One VSC that is bound to two AP groups using different egress VLANs

  Correct Answer: D

• Question 23:

  What is the general relationship between the coverage and the gain of a directional antenna?

  A. When the gain of the antenna is higher the antenna provides more diversity across the coverage area

  B. When the gain of the antenna is higher the coverage pattern is broader

  C. When the gain of the antenna is higher the coverage pattern is narrower

  D. When the gain of the antenna is higher the coverage area for the highest supported rates is higher

  Correct Answer: C

• Question 24:

  A customer decides to deploy two non-teamed controllers for a redundancy solution. What is one disadvantage of this solution as opposed to a teamed solution?

  A. In a failover situation, wireless users associated with a non-access-controlled VSC are disconnected.

  B. The guest solution cannot feature subscription or payment services

  C. The customer must purchase more AP licenses to support the same number of Aps with N+1 redundancy

  D. In a failover situation, wireless users associated with an access-controlled VSC must log in again.

  Correct Answer: A

• Question 25:

  Which VSCs require the implementation of opportunistic key caching?

  A. Any VSC that supports Layer 3 roaming

  B. All VSCs that are secured by WPA/WPA2-PSK or WPA/WPA2 with 802.1x

  C. Any VSC that is secured by WPA/WPA2 with 802.1x

  D. All access-controlled VSCs

  Correct Answer: C

• Question 26:

  Which feature is supported by an MSM720 but not by and MSM760?

  A. The ability to manage up to 200 Aps

  B. Teaming that is enabled through a premium license

  C. Fast roaming that is enabled through a premium license

  D. Multiple ports that you can combine in link aggregation groups

  Correct Answer: D

• Question 27:

  A network administrator is managing an existing MSM solution and changes the radio settings for a group of MSM APs controlled by an MSM controller. Which action must the network administrator take to apply the settings to the MSM APs?

  A. Click the Save button on the Radio configuration page to immediately apply the new configuration

  B. Click the Save button on the Radio configuration page and synchronize the MSM APs to the msm controller

  C. Click the Save button on the Radio configuration page and then reboot the MSM APs

  D. click the Apply Changes button on the VSC Binding page

  Correct Answer: B

• Question 28:

  Refer to the exhibit.



  Portion of the settings for VSC profile A VSC profile B and VSC profile C. A network administrator is deploying an HP MSM solution for a hotel. The solution consists of an HP MSM760 Access Controller, 50 HP MSM317 Access Devices, and several HP SMS460 Aps. The hotel plans to connect voice over IP (VoIP) phones to port 1 on each HP MSM317. To protect the ports from unauthorized access, the network administrator will configure the ports to support MAC authentication to accounts configured on the controller. The exhibit shows a portion of the settings for three VSCs Each VSC is enabled for MAC authentication.

  How can the network administrator configure port 1 on the MSM317s to meet this requirement?

  A. Configure switch port 1 at the controlled Aps level and bind VSC A to it.

  B. Configure switch port 1 at the controlled Aps level and bind VSC B to it.

  C. Configure switch port 1 at the controlled Aps level and bind VSC C to it.

  D. Configure switch port 1 at the controlled Aps level and enable MAC authentication on it.

  Correct Answer: B

• Question 29:

  The exhibit shows access lists configured on an HP MSM Controller. In addition, the controller has an account profile that specifies the "premium" access list. A network administrator applies this account profile to the user1 account. After user1 authenticates, which access list(s) does the controller apply to user1's traffic?



  A. Only premium

  B. First premium and then guests only

  C. First factory, then premium, and then guests

  D. First factory and then premium only

  Correct Answer: D

• Question 30:

  The Use Controller for Access Control option is selected of a VSC that is defined on an HP MSM Controller.

  The VSC enforces MAC-Auth to an external RADIUS server and also users a wireless MAC filter Allow list. A client attempts to connect to the WLAN associated with this VSC its MAC address is defined ass allowed on the external RADIUS

  server but is not listed on the VSC's Wireless MAC filter Allow list.

  What happens when the client attempts to connect?

  A. The client can connect and forward traffic and no errors are logged.

  B. The client cannot connect or forward traffic.

  C. The client can connect but can only forward traffic to devices on the wireless MAC filter allow list.

  D. The client can connect and forward traffic but an error is logged on the controller.

  Correct Answer: C
