Cisco CCNP Data Center 350-601 Questions & Answers

• Question 91:

  A UCS B- Series server located in B5108 chassis 1 slot 1 is currently unavailable. The server needs to be associated with a specific service profile when it becomes available. Which associate service profile option should be selected to accomplish this goal?

  A. server pool

  B. server

  C. custom server

  D. restrict migration

  Correct Answer: C

  https://www.cisco.com/en/US/docs/unified_computing/ucs/sw/gui/config/guide/141/UCSM_GUI_C onfiguration_Guide_141_chapter28.html



• Question 92:

  Refer to the exhibit.



  Which command needs to be added to the line starting with the "file" keyword to have the generated running-config file with the name `fusion-config_' and current date?

  A. ('fusion-config_ + date')

  B. str.('fusion-config_') + date

  C. string(('fusion-config_') + date)

  D. ('fusion-config_') + date

  Correct Answer: B

• Question 93:

  An engineer must configure a Nexus 7000 series switch for HSRP on VLAN 100. When fully functional, the router must be the active master.

  Which set of commands must be used to implement the scenario?

  A. feature hsrp interface vlan100 ip address 10.1.1.2 255.255.255.0 priority 255 preempt hsrp version 2 hsrp 1000 ip 10.1.1.1

  B. feature-set hsrp interface vlan100 ip address 10.1.1.2 255.255.255.0 priority 20 preempt hsrp version 2 hsrp 1000 ip 10.1.1.1

  C. feature-set hsrp interface vlan100 ip address 10.1.1.2 255.255.255.0 priority 80 preempt hsrp version 2 hsrp 1000 ip 10.1.1.1

  D. feature hsrp interface vlan100 ip address 10.1.1.2 255.255.255.0 priority 240 preempt hsrp version 2 hsrp 1000 ip 10.1.1.1

  Correct Answer: A

  Reference: https://www.google.com/search?q=hsrp+priorityandoq=hsrp+priorityandaqs=chrome..69i57j0l2j0i20i263i395j0i395l6.5307j1j4andsourceid=chromeandie=UTF-8

• Question 94:

  Port security is statically configured on a Cisco Nexus 7700 Series switch and F3 line card. The switch is configured with an Advanced Services license. Which two actions delete secured MAC addresses from the interface? (Choose Two)

  A. The address must be removed from the configuration.

  B. The address must reach the age limit that is configured for the interface.

  C. The interface must be converted to a routed port.

  D. The device must be restarted manually.

  E. Shutdown and then no shutdown must be run on the interface.

  Correct Answer: AC

  https://www.cisco.com/c/en/us/td/docs/switches/datacenter/sw/6_x/nx-os/security/configuration/guide/ b_Cisco_Nexus_7000_NX- OS_Security_Configuration_Guide__Release_6-x/b_Cisco_Nexus_7000_NXOS_Security_Configuration_Guide__Release_6-x_chapter_010001.html



• Question 95:

  Which file service protocol allows the files to appear locally mapped to the client and provides view, store, and update capabilities on a remote Linux-based storage repository that also serves as a distributed file system standard for NAS?

  A. NFS

  B. FTP

  C. iSCSI

  D. IFS

  Correct Answer: A

• Question 96:

  Which Cisco UCS Manager XML encoded backup type must be used to back up user names, roles, and service profiles?

  A. Full State Configuration

  B. Logical Configuration

  C. All Configuration

  D. System Configuration

  Correct Answer: C

• Question 97:

  A customer deploys a media server to distribute streaming videos to network clients. The requirement is to allow the video feed to reach only requesting clients. The shared trees must not propagate the video feed if no clients from that tree request it. To reduce configuration touchpoints, the solution must support the automatic discovery and announcement of RP-set information. Each router in the network is responsible for selecting the RP.

  Which configuration set meets these requirements?

  A. router(config-if)# ip pim bidir-enable router(config)# ip pim ssm default router(config)# ip igmp version 3

  B. router(config-if)# ip pim dense-mode router(config)# ip pim rp-address 1.1.1.1 router(config)# ip pim rp listener

  C. router(config-if)# ip pim sparse-sense mode router(config)# ip pim auto-rp router(config)# ip pim send-rp-announce

  D. router(config-if)# ip pim sparse mode router(config)# ip pim bsr-candidate Lo0 router(config)# ip pim rp-candidate Lo0

  Correct Answer: C

• Question 98:

  Refer to the exhibit.



  A network engineer must configure an authentication solution for Cisco UCS with these conditions:

  1.

  Two-factor authentication must be enabled for all UCS user authentication.

  2.

  All AAA packets must be encrypted and use TCP port 49 to establish communication.

  Which set of actions needs these requirements?

  A. Create the LDAP provider. Change the LDAP group rule in an LDAP provider.

  B. Create the RADIUS group mapping. Change the RADIUS group rule in a RADIUS provider.

  C. Remove the LDAP provider. Create a TACACS+ provider in user management.

  D. Delete the LDAP group mapping. Create a RADIUS provider in user management.

  Correct Answer: C

• Question 99:

  A new user with access privileges in the Finance department moves to a new Admin department. The user must have access privileges to the Admin department data and applications inside the Cisco UCS Manager.

  Which set of changes must be implemented in Cisco UCS Central for the user to acquire the privileges?

  A. Create an Admin user account and remove the authentication service for the Finance privileges.

  B. Disable the Finance user account and add the authentication service for the Admin privileges.

  C. Create a new locale Admin and add the Admin department to the Admin locale. Delete the old locale

  D. Finance and remove the Finance department from the Finance locale.

  Correct Answer: C

• Question 100:

  What is a benefit of using Cisco Tetration?

  A. It collects telemetry data from servers and then uses software sensors to analyze flow information.

  B. It collects near-real time data from servers and inventories the software packages that exist on servers.

  C. It collects policy compliance data and process details.

  D. It collects enforcement data from servers and collects interpacket variation.

  Correct Answer: A
